DIGITAL AIR PLASMA CUTTING MACHINE #KA-ACUT60
In stock
SKU:
WM02-PACUT60
- MCU Control
- HF ignition
- 2 step / 4 step
- Outstanding cutting quality
- Self-protections
- Recommended areas of use: Maintenance and repair, Industry plant and pipeline construction, Boiler and container construction, Metal shop, Steel construction
- Recommended base metals: Mild steel, Alloy steel, Stainless steel, Copper, Aluminum and other non-ferrous metals
- Mild steel cutting capability: 15mm/2.17”, at 60A and 30mm/1.18”, at 100A
- Stainless steel cutting capability: 15mm/2.17”, at 60A and 30mm/1.18”, at 100A
| Brands | KOVET |
|---|---|
| Rate Primary Voltage | AC380V (3 phase), ±10%, 50/60Hz |
| Arc-starting type | HF touch |
| Rated Input Capacity (KVA) | 7.7 |
| Maximum Input Current (A) | 21.5 |
| Rated input current (A) | 16.4 |
| Output Current Range (A) | 30 – 60 |
| Output Voltage (V) | 86 - 96 |
| Max No-Load voltage (V) | 345 |
| Pressure (bar) | 4 - 5.5 |
| Rate duty cycle at 100% (10min) | 46A |
| Efficiency (%) | 80 |
| Power Factor | 0.78 |
| Insulation grade | F |
| Protection Class | IP21 |
| Max cutting thickness (mm) | 15 |
| Material thickness (mm) | 1 - 10 |
| Weight (kg) | 28.5 |
| Dimension (LxWxH) (mm) | 501 x 232 x 495 |
| Cable Length (m.) | 3 |
