Inverter Air Plasma Cutting Machine #CUT-40CT
In stock
SKU:
WM04-CUT40CT
- Portable for carrying to any jobsite.
- Easy to connect to the air compressor. The welder can grab the torch and start cutting right away.
- Touch Start System – Smooth arc-striking with HF control.
- Rapid Arc Restrike – Quality narrow cutting and excellent travel speed.
- Good Cutting Thickness – Up to 10mm for carbon steel.
- Cool Operation, Long Consumable Life – Economical cutting accessories of good performance.
- Engine Drive Compatible – Wide range for input voltage, select a suitable engine drive in remote locations.
Energy saving - More efficient compared with the traditional cutting machine.
Brands | KOVET |
---|---|
Rate Primary Voltage | AC220V (1 phase), +/-15%, 50/60Hz |
Arc-starting type | HF, touch |
Rated Input Capacity (KVA) | 6.6 |
Maximum Input Current (A) | 30 |
Rated input current (A) | 16.4 |
Output Current Range (A) | 15 - 40 |
Output Voltage (V) | 86 - 96 |
Max No-Load voltage (V) | 275 |
Pressure (bar) | 4 - 5 |
Rate duty cycle at 30% (10min) | 40A 96V |
Rate duty cycle at 100% (10min) | 30A 92V |
Efficiency (%) | 80 |
Power Factor | 0.78 |
Insulation grade | F |
Protection Class | IP21 |
Max cutting thickness (mm) | 16 |
Material thickness (mm) | 1 - 10 |
Weight (kg) | 7.3 |
Dimension (LxWxH) (mm) | 402 x 160 x 300 |
Cable Length (m.) | 3 |
